Product Description

3 Phase 22K EV Wall Mount Box Fast Electric Car EV Charger Charging Station

Mechanical Properties
Mechanical life: no-load plug in 1 pull out > 10000times
Impact of external force :can afford 1m drop and 2t vehicle run over pressure

Electrical Performance
The rated current:16A(8/10/13/16A) 32A(8/10/13/16/32A)
The ratedvoltage:250V1415V
Insulation resistance:> 1000MQ ( DC500V) Terminal temperature rise: <50K
Withstand voltage:2000V Contact Resistance:0 5mQMax
Coupled insertion force: > 45N < 80N Operating temperature: 30C ~+50 C

Control Box Function
Leakage protection (restart recovery)
Over voltage and under -voltage protection (self- check recovery)
Lightning protection
Over current protection
Overheating protection
Black/other colors need to be customized

Applied Materials
Shell Material:thermoplastics flame retardant grade UL94-voContact bush: Copper alloy, silver plating
Pin: Copper alloy silver + thermoplastic on the top

Features
1. Conform to the provisions and requirements of 62196-2 IEC 2010 SHEET
2-lle.
2. Product assembly conforms to IEC 61851-1 -2010 charging mode 3 connection mode B2.3.Reliable materials,flame retardant,pressure resis-
tance, abrasion resistance ,impact resistance,lmpact resistance and oil resistance.
3. Excellent protection performance,IP65 protection level of the plug (work-
