Product Description
32A J1772 Type1 To 62196 Type2 Car Charger EV Cable
EV Charging cable for your electric vehicle. Charge from public charging stations or a dedicated charge point you have installed at home or commercial premises. We supply high specification electric vehicle charging cables for all vehicle types including electric motorbikes.
Specification
|
|
|
|
|
|
Insertion & Pullout Times
|
|
|
|
|
Insertion & Pullout Times
|
|
|
|
|
Withstanding Impact Force
|
|
|
|
Electrical Characteristics
|
Ambient Temperature(working)
|
|
|
|
Ambient Temperature(storage)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Product Feature
1. Meet the 62196-2 IEC 2010 SHEET 2-IIb standard
2. Nice shape, hand-held ergonomic design, easy to use
3. Safety design to prevent users from personal injuiry
4. Protection class: IP55 (in mated conditions)
5. Reliability of materials, antiflaming, environmental protection, abrasion resisitance, impact resistance, oil resistance and Anti-UV
Electrical Performance
1. Rated current:16A/32A/63A
2. Operating voltage: 250V AC
3. Insulation resisitance:>1000M(DC500V)
4. Therminal temperature rise:<50K
5. Withstand voltage:2000V
6. Vibration resistance:Meet JDQ53.36.1.1-53.36.1.2 requirements
7. Contact impedance: 0.5m Max
Materials
1. Shell material: Thermoplastic (Insulator inflammability UL94 V-0)
2. Contact Pin: Copper alloy, silver or nickel plating
3. Sealing gasket: rubber or silicon rubber
Mechanical properties
1. Mechanical life: no-load plug in/pull out >10000 times
2. Insertion and Extration Force: 45N<F<80N
Applications
Chevrolet Volt, Citroen C-Zero, Fisker Karma, Ford Focus Electric, Ford C-Max Energi, Mia, Mia Electric Van,Mitsubishi-I Miev, Mitsubishi Outlander Phev, Nissan NV200 SE Van, Nissan Leaf, Peugeot Ion, Renault Fluence,Renault Kangoo, Smiths Edison Van, Smiths Newton, Tata Indica Vista EV, Toyota Prius, Vauxhall Ampera...
