Detail Information

Product Name: 90Ah Lithium Iron Phosphate Battery Size: 130.3*36.7*200.5mm
Warranty: 36 Months-3year Application: Toys
Rate Discharge Ability At 25℃:: A) 0.5C(A)≥100% B) 1.0C(A) ≥100% Typical Voltage: 3.2V
Charging Working Temperature: 0℃~55℃ Discharging Working Temperature: -20℃~55℃
High Light:

90Ah Portable EV Battery

,

3.2V Portable EV Battery

,

LFP portable power for electric cars

Product Description

Rechargeable High Power Application Cell LFP Solar System Batteries 90Ah Lithium Ion Lifepo4 Battery Ev Car



1. Longer battery life – 5000times
2. Low self-discharge <3.5% per months
3. Free of charge memory
4. Steady discharge and charge performance.
5. Outstanding thermal stability
6. Wide temperature performance
7. Short circuit protection
8. Over charge and over discharge protection
9. Over current protection
10. Easy carrying and installation - can be carried and installed in any direction
11. Fast charging - about 4~6 hours to be fully charged
12. Lighter weight - 1/2~1/4 in weight compared to LA batteries
13. Require no change to a lead acid battery charging system
14. Better safety - mild warm, no explosion and firing, free of leakage
15. Environmentally friendly - no poisonous lead, no acid, no heavy/rare metals
16. No gasses during charge, free of leakage and pollution



Installation Instructions
Typical Capacity
90Ah
Typical Voltage
3.2V
AC Impedance Resistance
≤0.5mΩ
Standard charge and discharge Charge/Discharge Current
1C/1C
Standard charge and discharge Charge/Discharge Cut-off Voltage
3.65V/2.5V
Continuous Charge/Discharge Current
2C/2C
Pulse Charge/Discharge Ccurrent(30s)
3C/3C
Recommended SOC window
10%~90%
Charging Working Temperature
0℃~55℃
Discharging Working Temperature
-20℃~55℃
